A. Metal frame:
1. Material for upright frame: It’s made of 60X40X2.0mm steel pipe by welding,
it’s with epoxy resin powder after acid-washing and phosphorization.
2. Connection wing: solid plastic parts or welded steel part on O-frame itself, it
depends on customer’s requirement.
3. Adjustable feet: Using M10 screws(treated by galvanization) with adjustable
height not less than 10mm.
B.Worktop:
16mm phenolic resin worktop or 19mm epoxy resin worktop which are resistant
for chemicals and high temperature. The worktops can be washed easily. The
worktop can bear the weight about 200-300k.The gas height between worktop
<2mm.
C.Cabinet:
1. Door: The material is E1 standard 18mm plywood with melamine with 2mm
PVC water proof edgings.
2. Side panel and layer panel: The material is E1 standard 18mm plywood with
melamine with 2mm PVC water proof edgings.
3. Back panel: E1 standard 18mm plywood with 2mm PVC water proof edgings.
The back panel can be dissembled
and it’s convenient for installation and maintain of pipe and electricity cable.
4. Drawer: The material is E1 standard plywood with melamine with PVC water
proof edgings.
5. Drawer sliding rail: Using steel 3-joints weight bearing sliding rail without noise
on both sides of drawer.
6. Handle: Using stainless U-type specialized handle.
7. Hinge: 304 stainless steeel hydraulic hinge which is rust resistance.
