Window:
1.one whole piece of 5mm thick tempered safety glass sashes in aluminum alloy frame.
2. Controlled by new synchronizing belt transmission, sash can be stopped at any position by pulling up or down. Sash lifting force is only within 0.5KG. Horizontal sash can be custom- made if necessary.
3.Epoxy resin coated aluminum alloy sash handle is specially designed to ensure airflow to enter smoothly.
Exterior Structure: 1.0 mm thick galvanized steel by many processing procedures including folding, welding, polishing, acid cleaning, phosphorization, and coating with electrostatic, corrosion resistant powder.
Liner: 5 mm thick phenolic resin panels forming reasonable structure ensure organized airflow in good condition.
That can be easily disassembled for cleaning and reassembled. Acids, Alkalis, moisture and temperature resistant.
Working table: 19mm epoxy resin workop with 25mm edge which is continuous on all four sides of the worktop. Ceramic/phenolic resin worktop are for your option.
Lighting: 30 Watt antisepsis daylight lamp fitted in gas insulated housing to provide not less than 400 LUX of light flux on the working table.
Socket: Four sets of 220 volt/10 AMP multi-functional electric socket outlets with water proof cover.
Lab accessories:
1. Yellow brass, epoxy resin coated water control valve and cock.
2. Yellow brass, epoxy coated gas control valve and cock. The gas valve is with safety function to avoid air leakage, it will not be unintentionally turned on unless you press it.
Control panel:
LCD control panel which is capable of controlling ON/OFF of fume hood, lamp and fan. We can furnish control panel imported from France which can show face velocity,make alarm etc.
Storage Cupboard:
1. 3 or 4 double walled doors made of 1.0 mm thick galvanized steel and spray painted as specified above.
2. Stainless steel handles and S.S hydraulic hinges.
3. PP cup sink, resistant to acids, alkali and organic substance.
Remark:
1. We can add polypropylene storage cabinet or tray in the under cabinet to store strong chemicals in connection with main exhausting system.
2. We can furnish duct and fan if it’s required by customers.
3. We can furnish custom-built fume hood based on customer’s requirement.
